As demand for reliable internet connectivity grows, Starlink has established itself as a leading solution, particularly in remote and underserved areas. Routers, essential devices that connect multiple devices to the internet and facilitate local networking, play a crucial role in optimizing this connectivity. However, it’s important to note that not all Starlink kits come with a router.
Exploring Starlink Router Options
The Starlink Performance and Standard kit include the Gen 3 Router, designed specifically for everyday internet applications. In contrast, the Starlink Mini is a compact, portable kit that features a built-in router, making it ideal for users on the go. Additionally, earlier models like the Standard Actuated and High Performance offered the Gen 2 Router option, providing users with a range of connectivity solutions to suit their needs.
Starlink Router (Gen 2) vs. Starlink Router (Gen 3)
Starlink Routers Comparison Table
| Gen 2 Router | Gen 3 Router | Starlink Mini with integrated WiFi router | |
| Dimensions | 22.4 x 28.6 x 10 cm (8.8” x 11.3” x 4”) |
43.4 x 298.6 x 120.4 mm (1.7 in x 11.76 in x 4.74 in) |
Built-in |
| Wi-Fi Technology | IEEE 802.11a/b/g/n/ac standards | 802.11 a/b/g/n/ac/ax | 802.11 a/b/g/n/ac |
| Generation | Wi-Fi 5 | Wi-Fi 6 | Wi-Fi 5 |
| Radio | Dual Band – 3 x 3 MIMO | Tri Band 4 x 4 MU-MIMO | Dual Band 3 x 3 MU-MIMO |
| Ethernet Ports | No built-in ethernet port. Ethernet adapter sold separately. | Two latching Ethernet LAN ports | One latching Ethernet LAN port |
| Coverage | Up to 185m² (2,000sqft) | Up to 297 m² (3,200 ft²) | Up to 112 m² (1,200 ft²) |
| Operating Temperature | -30°C to 50°C (-22°F to 122°F) | -30°C to 50°C (-22°F to 122°F) | -30°C to 50°C (-22°F to 122°F) |
| Weight | 1 kg (2.2 lbs) | 0.57 kg (1.25 lbs) | 1.10 kg (2.43 lb) |
| Security | WPA2 | WPA2 | WPA2 |
| Environmental Rating | IP54, configured for indoor use | IP56, water-resistant, configured for indoor use | IP67 Type 4 with DC Power Cable and Starlink Plug/Cable installed |
| Devices | Connect up to 128 devices | Connect up to 235 devices | Connect up to 128 devices |
Speedcast’s Wi-Fi Extender Solution Expands the Range of Your Starlink Mini
For Starlink Mini users, there is an option to extend Wi-Fi coverage from 160 sqm to 465 sqm (5,000 ft²) with Speedcast’s Wi-Fi extender. Speedcast integrates the Mini with a Ubiquiti U7 Outdoor Access Point, enhancing performance through a mesh network. The U7 supports flexible antenna configurations, including internal directional and external omni 2×2 MIMO antennas across both 2.4 GHz and 5 GHz bands. The kit comes with a PoE+ adapter, Ethernet cable, and all necessary power supplies for the Starlink Mini.
Router Options for Enterprises
For enterprise users, the Starlink Performance (Gen 3) kit provides customers the flexibility to choose between the Starlink Gen 3 router for free and a third-party router. Users can connect a single device via the provided Ethernet cable or add a separate router for better management of multiple devices. Operating without a router can severely limit network management capabilities, complicating the control and direction of internet traffic.
For those seeking a comprehensive solution, Speedcast’s SIGMA network management platform is the answer. SIGMA integrates Starlink with various connectivity paths, including LEO, GEO, MEO, L-band, cellular, and microwave, creating a single virtual wide-area network. This diverse routing enables 100% uptime and optimized bandwidth usage, crucial for businesses operating in remote locations.
Key Benefits of SIGMA:
- Enhanced Visibility and Control: Gain insights and control over remote sites with ease.
- Cost Efficiency: Smaller routing functions combined with reduced hardware costs allow better resource management.
- Automation: Streamline the deployment and updating processes for both SIGMA software and customer applications at the edge.
- Central Orchestration: Manage thousands of edge devices effectively, reducing reliance on cloud processing and improving performance.
- Unmatched Flexibility: Customize and visualize your service anytime, enhancing overall network performance and security.
Make the Smart Choice for Connectivity
Choosing the right router is essential to maximizing your Starlink experience. While the Starlink Standard and Mini kits offer options for residential and portable use, enterprise customers will find significant benefits in integrating Speedcast’s SIGMA device. With its advanced features and capabilities, SIGMA enhances connectivity and provides the necessary tools for effective network management.
Contact Speedcast today to learn more about how SIGMA can unlock the full potential of your Starlink service.
Speak with our experts.
